ICON 2010-2023 Toyota 4Runner suspension systems are designed with maximum performance and the serious driver in mind. ICON engineers’ primary focus is to increase wheel travel and damping ability, which translates into outstanding vehicle control and ride quality both on and off-road.

This Lift Kit includes vehicle-specific tuned, extended travel 2.5” coilover shocks featuring CDEV equipped remote reservoirs for exceptional cooling properties and ICON-engineered coil springs for superior vehicle “feel” through the range of travel. Focus on driving and let ICON Intelligent Control (IIC) read the terrain and make near-instant adjustments via the Compression Damping Electronic Valve (CDEV) at each individual shock. Control the system wirelessly through the IIC app on your phone and once configured the system functions without driver input. These coilovers are also height adjustable for 0-3.5” of front lift over stock, allowing the use of larger, more aggressive wheel and tire combos. ICON rear coil springs deliver on-road comfort and superior off-road performance with 2” of rear lift height over stock for a level stance front to rear.

The 2.5 Aluminum Series CDEV remote reservoir rear shocks’ larger diameter offers outstanding performance off-road and a smooth ride on the street with active, adjustable compression damping.

Increased wheel travel and ride quality over stock.
Vehicle specific tuned front and rear shocks for superior shock damping and control.
ICON's CDE Valve technology allows for in vehicle adjustment of compression damping settings and active adjustment via the ICON Intelligent Control (IIC).
ICON Intelligent Control (IIC) uses onboard sensors to monitor G-forces and movement of vehicle chassis along with user defined settings to actively make near instantaneous compression damping changes.
Adjustable coilovers provide 0-3.5" of front lift height.
Extended Travel remote reservoir coilovers matched with ICON UCAs provide increased front droop travel.
6061 aircraft grade aluminum CNC machined components.
Corrosion resistant CAD plated coilover shock bodies with 7/8" shafts.
2.5 Aluminum Series rear shocks feature one-piece impact extruded aluminum cylinders for excellent corrosion resistance and consistent finish.

Other details

Easy bolt-on installation.
Est. Install Time: 2-4hrs.
Recommended Tire Size: 285-70R17 (32.76”), 285-55R20 (32.60”).
Recommended Wheel Backspacing: Factory.
