Fuel 1PC D714 Contra Platinum - 20X9 02mm - Brushed Gun Metal Tinted Clear

Wheel Specs
Brand	Fuel 1PC
Model Name	D714 20.0X9 6X135/5.5 BRSH-GNMTL-TTC 02MM
Part Number	D71420909849
Finish	BRUSHED GUN METAL TINTED CLEAR
Material	Cast Aluminum
Size	20.0X9
Width	9
Diameter	20
Bolt Pattern	6X135/6X139.7
Backspace	5.08
Cap Part No	1003-81FLRT
Offset	02
Hub/Center Bore	106.10
Weight	40.00
Load Rating	2500
Lip Depth	0.00
UPC	885463922768
Finish Warranty	ONE YEAR
Structural Warranty	LIFETIME
Lug Count	6
